Category: Access#

The Access category documents the access paths to an object. It is a multi-value category -- multiple entries can be created per object, e.g. a web interface on port 443, an SSH access on port 22, and an iDRAC remote console for out-of-band management.

Usage#

Typical use cases:

• Quick access from the CMDB: Store the URL to the web interface of a server, firewall, or network switch. i-doit renders the entry as a clickable link -- one click is all it takes to jump directly to the device in your browser without having to look up the address first. The primary access even appears in the object list -- you don't even need to open the object to use the link.
• Emergency documentation: During an incident, every second counts. When SSH access, iLO console, and IPMI address are already recorded in the CMDB, the on-call team can find the right access path immediately -- even at night, even without prior knowledge of the system. Combine the Access category with the Contact assignment category to know not only how to reach a system, but also who is allowed to access it and who is responsible in case of an outage.
• Onboarding new employees: New colleagues receive a structured overview of all relevant entry points via the Access category: the ticket system via HTTPS, the monitoring server via SSH, the database via RDP to the jump host. This way, the CMDB becomes the central hub for getting started with the IT landscape.
• Overview of access methods: The Report Manager can evaluate which objects use which access types -- helpful for finding all systems that still use unencrypted HTTP or Telnet, for example. A report like "All objects with access type Telnet" uncovers security gaps before the auditor does.
• Integration with network documentation: In combination with Host address, a complete picture emerges: the host address documents the IP, the Access category documents the specific service and port. For a monitoring system, this could mean: Host address 10.10.1.50, Access https://10.10.1.50:9090 (Prometheus UI).

Fields#

Title#

A descriptive name for the access entry, e.g. Web Interface, SSH Access, iDRAC Remote Console, or Monitoring Dashboard. The title appears in the list view of the category and in reports. Choose a name that makes it immediately clear where the link leads and what it is used for.

Access type#

The type of access -- i.e. the protocol or technology used. Dialog+ field with predefined values such as HTTP, HTTPS, SSH, RDP, Telnet, iLO, or iDRAC. Custom values can be added as needed, e.g. VNC, IPMI, or WinRM. The access type determines how i-doit formats the URL in the view and which scheme is used when clicked.

Host[:Port]/URL#

The complete address of the access point. Enter the URL or connection string here, e.g. https://srv-web-01.bhb.local:8443, ssh://admin@10.10.1.100, or rdp://jumphost.intern.local. i-doit renders this value as a clickable link. Make sure to include the protocol prefix and, if applicable, the port so that the link works directly.

Primary access#

Indicates whether this entry is the preferred access path to the object. Dialog field with values Yes and No. Exactly one entry per object should be marked as primary -- this entry is displayed prominently in overviews and the object list. Typically, this is the web interface or the most frequently used access path.

Description#

Free text for additional notes: credential references (e.g. "Credentials in password manager under entry XY"), special requirements (VPN required, client certificate needed), or restrictions (only accessible from the management network, intended for emergencies only).

Technical reference#

Fields (API reference)#

API examples#

Create entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATG__ACCESS",
        "data": {
            "title": "Web Interface",
            "type": "HTTPS",
            "url": "https://srv-web-01.bhb.local:8443",
            "primary": 1,
            "description": "Admin panel, VPN access required. Credentials in password manager."
        }
    },
    "id": 1
}

Read entries#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.read",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATG__ACCESS"
    },
    "id": 2
}

Update entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATG__ACCESS",
        "entry": 32,
        "data": {
            "title": "SSH Access",
            "type": "SSH",
            "url": "ssh://admin@10.10.1.100",
            "description": "Maintenance access for system administrators."
        }
    },
    "id": 3
}
