Category: Desktop#

The Desktop category captures client-specific properties of an end device. It is a single-value category and is available as a specific category on objects of the type Client.

Usage#

Typical use cases:

  • Document client type: Distinguish between desktop, laptop, tablet, thin client or other form factors. The Dialog+ field allows the addition of custom types — such as Kiosk Terminal or Ruggedized Notebook.
  • Record keyboard layout: Record whether a device is equipped with a German (QWERTZ), English (QWERTY) or another layout. Helpful during device replacement and for IT support, especially in international organizations.
  • Reporting and filtering: The Report Manager can filter by client type — e.g. "all laptops with Windows 11" or "all thin clients at the Berlin location". In combination with the categories Model and Operating system, this creates a comprehensive end device profile.

Distinction from the Model category

The Desktop category is specific to client objects and offers a dedicated Dialog+ field for the client type. General hardware attributes such as manufacturer and model belong in the category Model.

Desktop

Fields#

Client type#

The form factor or type of the client, e.g. Desktop, Laptop, Tablet or Thin Client. Dialog+ field — custom values can be added as needed.

Keyboard layout#

The physical keyboard layout of the device, e.g. QWERTZ (DE), QWERTY (US) or AZERTY (FR). Free text field with a maximum of 255 characters.

Description#

Free text for supplementary details, e.g. special peripherals, docking station compatibility or notes on usage.

Technical Reference#

Property Value
Category Constant C__CATS__CLIENT
Type Specific category
Multi-Value No (single-value)
Assigned to Client

Fields (API Reference)#

Field API Key Type
Client type type Dialog+ (extensible selection)
Keyboard layout keyboard_layout Text
Description description Text field (multi-line)

API Examples#

Create Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 101,
        "category": "C__CATS__CLIENT",
        "data": {
            "type": 1,
            "keyboard_layout": "QWERTZ (DE)",
            "description": "default workstation, incl. Docking Station HP UltraSlim"
        }
    },
    "id": 1
}

Read Entries#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.read",
    "params": {
        "apikey": "your-api-key",
        "object": 101,
        "category": "C__CATS__CLIENT"
    },
    "id": 2
}

Update Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 101,
        "category": "C__CATS__CLIENT",
        "entry": 1,
        "data": {
            "type": 2,
            "keyboard_layout": "QWERTY (US)",
            "description": "Switched to laptop, international layout"
        }
    },
    "id": 3
}
