Category: Database Links#

The Database Links category documents connections between database schemas — so-called database links, synonyms, or federated table configurations. It is a multi-value category and allows recording any number of links per schema.

Usage#

Typical use cases:

• Document Oracle database links: Oracle databases use DB links to access remote tables across schemas. With this category, you can record every link with target schema, owner, and visibility (public/private).
• Make cross-schema dependencies visible: When a schema accesses another via a DB link, a dependency is created. Through the link to the target schema in i-doit, this dependency is navigable and appears in impact analyses.
• Safeguard change planning: Before a schema migration, a look at this category shows which links reference the schema — a missing DB link after migration would otherwise lead to runtime errors.
• Permission documentation: The fields Target user and Owner show under which database user the access occurs and who manages the link.

Fields#

Title#

The name of the database link, e.g. REPORTING_LINK or HR_REMOTE.WORLD. This value corresponds to the identifier under which the link is referenced in SQL statements (e.g. SELECT * FROM table@REPORTING_LINK).

Connected database schema#

Link to the target database schema as an i-doit object. Via the object browser, the schema that the link points to is selected. This creates a bidirectionally navigable relationship.

Target user#

The database user under whose identity the access to the target schema occurs, e.g. REPORTING_RO. Relevant for permission audits and security documentation.

Owner#

The owner of the database link — i.e. the schema or user in whose possession the link resides, e.g. APP_OWNER. For public links, this is typically PUBLIC or a DBA account.

Public#

Indicates whether this is a public database link available to all users of the database instance, or a private link accessible only to the owner.

Description#

Free text for additional details: purpose of the link, associated applications, planned replacement, notes on network connectivity or TNS configuration.

Technical Reference#

Fields (API Reference)#

API Examples#

Create Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__DATABASE_LINKS",
        "data": {
            "title": "REPORTING_LINK",
            "link": 456,
            "target_user": "REPORTING_RO",
            "owner": "APP_OWNER",
            "public": 1,
            "description": "Public DB link to reporting schema, used by BI application"
        }
    },
    "id": 1
}

Read Entries#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.read",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__DATABASE_LINKS"
    },
    "id": 2
}

Update Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__DATABASE_LINKS",
        "entry": 1,
        "data": {
            "target_user": "REPORTING_RW",
            "description": "Permission change: write access since 2026-04"
        }
    },
    "id": 3
}
