Category: Database Objects#

The Database Objects category documents the individual objects within a database schema — i.e. views, stored procedures, functions, triggers, sequences, and other named elements. It is a multi-value category, since a schema typically contains many such objects.

Usage#

Typical use cases:

  • Create schema inventory: Record all relevant database objects of a schema — from critical views through central stored procedures to trigger logic. This creates a documented inventory of the database structure.
  • Impact analysis for schema changes: Before a table is changed or deleted, the list of database objects shows which views, procedures, or functions could be affected. This reduces the risk during deployments.
  • Clarify application dependencies: When an application uses specific views or stored procedures, this can be documented here. In combination with the category Database access, a clear picture emerges of which application uses which objects.
  • Automated import: Via the API, you can automatically import database objects from database catalog tables (e.g. information_schema.routines or ALL_OBJECTS) to keep the documentation up to date.

Database category chain

This category belongs to the database category chain in i-doit. Together with Database schema, Database gateway, Database links, and Database access, these categories form a complete database documentation.

Database Objects

Fields#

Title#

The name of the database object, e.g. v_active_users, sp_generate_report, or trg_audit_log. Should exactly match the name in the database to enable a unique mapping.

Type#

The type of the database object. Dialog field with values such as View, Procedure, Function, Trigger, Sequence, Package, etc. Enables filtering and evaluation by object type in reports.

Tip: Reports by object type

In the Report Manager, you can filter by the Type field, e.g. to list all stored procedures across all schemas — useful for audits or migration planning.

Description#

Free text for additional details: purpose of the object, associated business logic, dependencies on tables, performance notes, or migration status.

Technical Reference#

Property Value
Category Constant C__CATS__DATABASE_OBJECTS
Type Specific category
Multi-Value Yes
Assigned to Database schema

Fields (API Reference)#

Field API Key Type
Title title Text
Type database_object Dialog (selection)
Description description Text field (multi-line)

API Examples#

Create Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__DATABASE_OBJECTS",
        "data": {
            "title": "v_active_users",
            "database_object": "View",
            "description": "View on active user accounts, used by the user management module"
        }
    },
    "id": 1
}

Read Entries#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.read",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__DATABASE_OBJECTS"
    },
    "id": 2
}

Update Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__DATABASE_OBJECTS",
        "entry": 1,
        "data": {
            "title": "v_active_users_v2",
            "description": "Updated view with additional filter on tenant"
        }
    },
    "id": 3
}
