Category: Room#

The Room category documents the room-specific properties of a room object: room type, floor, room number, and an optionally description. It is a specific category that is exclusively available for objects of the type Room.

Rooms form a central level in the location hierarchy in i-doit. They are typically subordinate to a building or floor and in turn contain racks, workstations, or individual devices. The location assignment itself is made through the global Location category -- the Room category supplements this with room-specific additional information.

Usage#

Typical use cases:

• Building a room directory: Record all rooms of a building with room number, floor, and type. In combination with the Location category, this creates a navigable building structure: Location > Building > Floor > Room > Rack > Server. The location browser in i-doit visualizes this hierarchy as a tree structure.
• Classifying data center rooms: Through the "Type" field, you can distinguish between server rooms, network distribution rooms, UPS rooms, and office rooms. A report such as "All rooms of type server room" provides a quick overview of all IT-critical spaces -- helpful for fire protection and access control concepts.
• Relocation and room planning: During office relocations or room swaps, the location hierarchy under the respective room immediately shows which devices (printers, phones, monitors, PCs) are in that room and need to be moved.
• Facility management and audit: In regulated environments (ISO 27001, BSI IT-Grundschutz), rooms with IT infrastructure must be documented -- including type, location, and protective measures. The Room category provides the basic information, which can be supplemented by custom categories (e.g. access control, air conditioning).

Fields#

Type#

The room type, e.g. Office, Server Room, Network Distributor, Storage, Conference Room, or Technical Room. Dialog+ field -- custom values can be added as needed. The type is the most important distinguishing characteristic in reports and filters: It determines whether a room is classified as IT-critical and which protection requirements apply.

Room number#

The official room number or designation according to the building plan, e.g. G.03.012 (ground floor, building section 03, room 012) or 2-214. This field should follow the naming scheme of the facility management so that the i-doit documentation is consistent with physical door signs and building plans.

Floor#

The floor or story where the room is located, e.g. GF, 1F, B1, or 3. Free text field -- a uniform scheme within the organization is recommended. The floor can alternatively be represented as its own object in the location hierarchy (Building > Floor > Room), but is documented here as quick supplementary information directly on the room.

Description#

Free text field for supplementary information: room size (sqm), number of workstations, special equipment (raised floor, air conditioning, fire alarm system), access restrictions, contact person, or usage notes.

Technical Reference#

Fields (API Reference)#

API Examples#

Create Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 300,
        "category": "C__CATS__ROOM",
        "data": {
            "type": "Serverraum",
            "number": "E.03.012",
            "floor": "EG",
            "description": "Server room building section 03, raised floor, air conditioning, access only with transponder"
        }
    },
    "id": 1
}

Read Entries#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.read",
    "params": {
        "apikey": "your-api-key",
        "object": 300,
        "category": "C__CATS__ROOM"
    },
    "id": 2
}

Update Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 300,
        "category": "C__CATS__ROOM",
        "entry": 1,
        "data": {
            "type": "Netzwerkverteiler",
            "description": "Repurposing 2025-06: Server room to network distributor, active cooling removed"
        }
    },
    "id": 3
}
