Category: Routing#

The Routing category documents the routing configuration of a router object. It is a specific category and is exclusively available for the object type Router. Here it is recorded which routing protocol the router uses and which gateway addresses are configured — information that is indispensable for network documentation and troubleshooting.

Specific category

Routing is a specific category that is only assigned to the object type Router. For documenting the network connectivity of other devices, the global categories Host address and Port are available.

Usage#

Typical use cases:

  • Document network topology: Record the deployed routing protocol (e.g. OSPF, BGP, RIPv2, static) and the configured gateway addresses. Together with the categories Net and Port, this provides a complete picture of the network infrastructure.
  • Troubleshooting and error analysis: When a network segment is unreachable, a look at the Routing category immediately shows which protocol the affected router uses and which gateways are configured. This significantly accelerates fault isolation.
  • Change Management: When switching routing protocols — for example from static routing to OSPF — archive the old entry and create a new one. The change history then seamlessly shows when which configuration was active.
  • Compliance and Audits: In regulated environments, documentation of the routing configuration is often required. Using the Report Manager, you can generate a complete overview of all routers and their protocols at any time.

Interaction with WAN connections

Routers are frequently located at the transition between LAN and WAN. Document the WAN connection in the category WAN connections and link the router there via the field Connected routers. This creates a seamless chain from the WAN connection through the router into the local network.

Category Routing

Fields#

Routing protocol#

The routing protocol configured on the router, e.g. OSPF, BGP, RIPv2, EIGRP or Static. Dialog+ field -- custom values can be added as needed. For routers that use multiple protocols simultaneously (e.g. OSPF internally and BGP externally), it is recommended to document the primary protocol and supplement details in the description field.

Gateway address#

The IP address configured as the gateway. This field links to addresses maintained in the category Host address. For routers with multiple interfaces and different gateways per network segment, the relevant addresses can be assigned here.

Description#

Free text for additional details: OSPF area, BGP AS number, route maps, ACLs, special configuration features or references to the configuration file in the version control system.

Technical Reference#

Property Value
Category Constant C__CATS__ROUTER
Type Specific category
Multi-Value No
Assigned to Router

Fields (API Reference)#

Field API Key Type
Routing protocol routing_protocol Dialog+ (extensible selection)
Gateway address gateway_address Dialog list
Description description Text field (multi-line)

API Examples#

Create Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__ROUTER",
        "data": {
            "routing_protocol": "OSPF",
            "description": "OSPF Area 0, Router-ID 10.0.0.1, Redistribution of static routes"
        }
    },
    "id": 1
}

Read Entries#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.read",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__ROUTER"
    },
    "id": 2
}

Update Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__ROUTER",
        "entry": 1,
        "data": {
            "routing_protocol": "BGP",
            "description": "Migration from OSPF to BGP completed, AS 65001."
        }
    },
    "id": 3
}
