Category: Service#

The Service category documents the master data of an IT service object. It is a specific category available for the object type Service. Here, fundamental properties such as specification, manufacturer, installation type, and license information are recorded -- the technical foundation on which service assignments, SLAs, and business criticality assessments are built.

Usage#

Typical use cases:

• Building a service catalog: Record the specification, manufacturer, and installation type for every service. This creates a structured service catalog that serves as the foundation for ITSM processes. A report on all services with manufacturer and installation status shows at a glance which services are in use.
• License management: Through the registration key and the number of installations, you can track how many instances of a service are licensed and actually installed. In combination with the Service Assignment category, this creates a complete picture of license usage.
• Installation documentation: The installation path and installation type (manual, automated, package manager) document how and where the service was provisioned. This is particularly valuable for change management and when migrating to new platforms.
• Manufacturer overview: Using the Report Manager, you can evaluate which manufacturers are represented in the service catalog -- helpful for vendor consolidation and contract negotiations.

Fields#

Specification#

A free text description of the service, e.g. E-mail server for the sales department or Monitoring agent v3.2. The functional description or technical specification of the service can be stored here.

Manufacturer#

The manufacturer or provider of the service, e.g. Microsoft, Apache Foundation, or In-house development. Dialog+ field -- custom values can be added as needed.

Installation#

The type of installation, e.g. Manual, Silent, Package Manager, or Container. Dialog field with predefined options.

Registration key#

The license or registration key for the service. Note: In sensitive environments, the complete key should not be stored in the CMDB -- a reference to the vault or license management system is often the better choice.

Installation path#

The path where the service is installed, e.g. /opt/monitoring-agent/ or C:\Program Files\Service\. Helpful for troubleshooting and uninstallation.

Installation count#

The total number of installations of this service in the environment. Useful for the license overview and capacity planning.

Description#

Free text for additional details: version number, dependencies, configuration notes, known limitations, or references to documentation.

Technical Reference#

Fields (API Reference)#

API Examples#

Create Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__SERVICE",
        "data": {
            "specification": "Zentraler Monitoring-Dienst für alle Productionsserver",
            "manufacturer": "Zabbix LLC",
            "installation": "Paketmanager",
            "registration_key": "Siehe Lizenztresor",
            "install_path": "/opt/zabbix-server/",
            "installation_count": 1,
            "description": "Zabbix Server 6.4 LTS, PostgreSQL-Backend, aktive und passive Checks"
        }
    },
    "id": 1
}

Read Entries#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.read",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__SERVICE"
    },
    "id": 2
}

Update Entry#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

{
    "jsonrpc": "2.0",
    "method": "cmdb.category.save",
    "params": {
        "apikey": "your-api-key",
        "object": 123,
        "category": "C__CATS__SERVICE",
        "entry": 1,
        "data": {
            "specification": "Zentraler Monitoring-Dienst — erweitert um Cloud-Monitoring",
            "installation_count": 3,
            "description": "Zabbix Server 7.0 LTS, upgrade 2025-09, now with Zabbix Proxy at two remote sites."
        }
    },
    "id": 3
}
