Object Type: Switch Chassis#

The Switch Chassis object type documents modular switch systems with a chassis that holds interchangeable line cards. Switch chassis are high-end switches used in data centers and campus networks.

Usage#

• Modular Architecture: Document the chassis with its slots and installed line cards.
• Port Management: Record ports across all line cards.
• Network Infrastructure: Assign the switch chassis to its location and connected networks.

Assigned Categories#

Global Categories#

• General
• Location
• Locally assigned objects
• Model
• Power Consumer
• Network Port
• Network
• Port
• Port Overview
• Logical Ports
• Logbook
• VRRP Membership

Specific Category#

The specific category for this object type is Chassis. The specific category for this object type is Slots. The specific category for this object type is Assigned devices. The specific category for this object type is Chassis view. The specific category for this object type is Chassis cabling.
